CE6856-48T6Q-HI 48-Port 10G 6x40G Data Center Switch
Premium Products
CE6856-48T6Q-HI 48-Port 10G 6x40G Data Center Switch
1
2
3
4
5
6
Brand Name :/
Model Number :CE6856-48T6Q-HI
Place of Origin :Shanghai, China
MOQ :2
Price :$5,975-6,155
10G Ports :48
40G Ports :6
Transmission Rate :10/100/1000Mbps
Switch Capacity :10g
Processor Speed :1.2 GHz
DRAM Memory :4 GB
NOR Flash :16 MB
NAND Flash :1 GB
AC Input Voltage :100 V AC to 240 V AC
DC Input Voltage :-48 V DC to -60 V DC
Power Consumption :346 W (max)
Operating Temperature :0 °C to 40 °C
Noise Level :< 53 dBA
Surge Protection :2 kV (Ethernet), 4 kV (Power)
MTBF :54.48
Contact Now
Product Description
CloudEngine 6850 (CE6850 for short) series switches are next-generation 10G Ethernet switches designed for data centers and high-end campus networks, providing high-performance, high-density 10GE ports, and low latency. The CE6850 series uses an advanced hardware architecture with 40GE uplink ports and the industry's highest density of 10GE access ports. Using the VRP8 software platform, CE6850 switches provide extensive data center service features and high stacking capability. In addition, the airflow direction (front-to-back or back-to-front) can be changed. CE6850 switches can work with CE12800 switches to build an elastic, virtualized, high-quality fabric that meets the requirements of cloud-computing data centers. CE6850 switches provide high-density 10GE access to help enterprises and carriers build a scalable data center network platform in the cloud computing era. They can also be used as aggregation or core switches for enterprise campus networks.
General Information
Product Model: CE6856-48T6Q-HI
Product Series: CloudEngine 6800 Series1
Ports
10GBASE-T Ethernet Electrical Ports: 48 ports, RJ45 connector type, compliant with IEEE 802.3an and IEEE 802.3az standards, supporting straight-through and crossover cables, with a working mode of 100/1000 Mbit/s and 10 Gbit/s auto-sensing, full-duplex, and a maximum transmission distance of 100 m.
40GE QSFP+ Ethernet Optical Ports: 6 ports, LC/MPO connector type, optical port attributes depending on the module or cable in use, compliant with IEEE 802.3ba standard, working mode is full-duplex.
ETH Management Interfaces: 2 ports, combo type, with the GE optical interface of the combo port supporting FE SFP_eSFP
Console Interface: RJ45 connector type, compliant with RS232 standard, working mode is duplex universal asynchronous receiver/transmitter (UART), baud rate from 9600 bit/s to 115200 bit/s, default value is 9600 bit/s.
Performance
Processor: 1.2 GHz, quad-core.
DRAM Memory: 4 GB.
NOR Flash: 16 MB.
NAND Flash: 1 GB.
Power
Power Source Type: AC/DC/High-Voltage DC.
AC Power Input: Rated input voltage range is 100 V AC to 240 V AC, 50/60 Hz; maximum input voltage range is 90 V AC to 290 V AC, 47 Hz to 63 Hz.
DC Power Input: Rated voltage range is -48 V DC to -60 V DC; maximum voltage range is -38.4 V DC to -72 V DC.
High-Voltage DC Power Input: Rated voltage of 240 V high-voltage DC power input is 240 V DC, maximum voltage range is 188 V DC to 290 V DC; rated voltage range of 380 V high-voltage DC power input is 240 V DC to 380 V DC, maximum voltage range is 188 V DC to 400 V DC.
Rated Input Current: 600 W AC & 240 V DC power module (PAC-600WB series) is 8 A (100 V AC to 240 V AC) / 4 A (240 V DC); 600 W high-voltage DC power module (PHD-600WA series) is 4 A (240 V DC to 380 V DC); 1200 W DC power module (PDC-1K2WA series) is 38 A (-48 V DC to -60 V DC).
Chassis Power Consumption: Maximum power consumption is 346 W, typical power consumption is 219 W (100% throughput, 3 m Ethernet cables on 48 ports and QSFP+ cables on 6 ports, double power modules).
Chassis Heat Dissipation: Maximum heat dissipation is 1181 Btu/hr, typical heat dissipation is 747 Btu/hr (100% throughput, 3 m Ethernet cables on 48 ports and QSFP+ cables on 6 ports, double power modules).
Environmental
Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) at altitude of 0 – 1800 m (0 – 5906 ft.).
Storage Temperature: -40 °C to +70 °C (-40 °F to +158 °F).
Relative Humidity: 5% rh to 95% rh, noncondensing.
Altitude: < 5000 m (16404 ft.).
Noise: < 53 dBA (back-to-front airflow or front-to-back airflow, at 27 °C).
Mechanical
Dimensions: Not specified in the provided data.
Weight: Not specified in the provided data.
Other
Surge Protection: Ethernet electrical ports have 2 kV in common mode; power module has 4 kV in common mode and 2.5 kV in differential mode for AC, and 4 kV in common mode and 2 kV in differential mode for DC.
Airflow: Front-to-back or back-to-front, depending on the fan modules and power modules1.
Reliability and Availability: Power module backup is 1+1 backup, fan module backup is 1+1 backup (Note: a CE6800 chassis uses two fan modules, with each fan module containing two fans. The four fans in the chassis work in 3 + 1 backup mode).
Hot Swap: All power modules and fan modules support hot swap.
Mean Time Between Failures (MTBF): 54.48.
Mean Time to Repair (MTTR): 1.81.
